Features of The Binary Rig

Inputs & Connectivity

The Binary Rig offers industry standard I/O for audio, monitoring, and power output.

Power for accessories is distributed via three 12v Anton Bauer P-Tap connectors. The power distribution circuit allows for the full 10amps of standard video and cinema batteries to be used. There are two 12-14v power inputs that are voltage and polarity protected. The Binary Rig uses a 6 pin "RED camera" style LEMO connector (or, alternatively, a 4 pin XLR power input). The two power inputs can be hot swapped allowing for continuous functionality during power repatching.

Cameras that output a composite video feed (such as the Canon 5D) can take advantage of the interregnal composite output. That signal is also routed out through the chassis's top plate, and can be converted to SDI with the ECC Tools HD-SDI module.

Cameras that output a clean HDMI feed (such as the Canon 7D) can take advantage of the HDSDI module. All module signal conversions are run through highly reliable and industry-standard AJA hardware boards.

The Binary Rig also passes through full size USB I/O for software control and future hardware expansion. The USB signal is processed through a buffer, so signal integrity remains reliable when devices are connected.

The program-in LEMO connector on the chassis allows the user to modify the firmware to send the specific IR codes to the camera, for functions such as rolling the camera. Additionally, a 32-pin LEMO camera-model-specific pigtail interprets individual camera controls via a secure, high-grade connection that can easily be swapped when changing cameras.

Audio Integration

One of the major drawbacks of shooting with a DSLR camera, is their lack a proper audio control. The Binary Rig allows the user to have full control over the stereo input of the camera. The input can be switched between line and mic levels, and The Binary Rig will output phantom power to microphones if desired. Levels can be metered with a ten-step LED readout and adjusted through the gain control knobs located on the side of the rig.

If you've tried to record directly into a DSLR, you're familiar with the issue of AGC (auto gain contro). This "feature" creates noise on the audio track by automatically attempting to level the input audio, taking control away from the user. The Binary Rig solves this problem by sending tone to the camera automatically, dropping the gain to the bottom of its range. This feature is easily toggled via a switch on the rig for cameras that do not possess the ACG "feature".

Modularity

The Binary Rig was built with modularity in mind. Every mechanical part of the rig can be taken apart for the specific needs of the job at hand. Users can purchase electrical modules that sit in on top of the chassis, increasing capabilities of the rig. The heart of the module mantra is the signal conversion, however new products are currently in development to offer functions such as: audio recording, gen-locking, GUI camera control and slim, high density battery packs.

Whether you're using 15mm LWS with the included baseplate, or looking to support cinema lenses with an Arri or Element Technica 15mm/19mm studio plate, The Binary Rig can handle nearly any camera configuration. Industry-standard pin hole registration and mounting alignment under the baseplate insures the user's matte box will align with the center of the lens in any configuration.

Structural Innovation

All the mechanical parts in The Binary Rig are made out of high grade machined aluminum. Mounting points for standard ¼ and ⅜ are placed strategically at many points to allow such items as battery mounts, support arms, and quick releases to be conveniently mounted.

The Binary Rig includes a high grade handle that is double-mounted with heavy duty ⅜ bolts, allowing the camera to be safely transported when it is built up a heavy configuration (such as with a long zoom lens).

The cage surrounding the camera is both protective and functional; it allows the user to access the media doors, while hiding and protecting the vulnerable connections of the camera.
